D/A CONVERTER CHIP: AKM AK4493 PCM up to 32bit/768kHz and DSD512
FREQUENCY RESPONSE: 20Hz-20kHz +/-0.1dB
THD (Total Harmonic Distortion): 0.001% max
SIGNAL TO NOISE RATIO: 125dB
DYNAMIC RANGE: 120dB
PREAMP STAGE VOLUME CONTROL: Enabled/Disabled
NETWORK CONNECTIVITY: LAN/WLAN (WiFi) 802.11a/b/g/n/ac Dual Band (10/433Mbps), Bluetooth: High Definition 5.0 (44/16)
HIGH QUALITY STREAMING: Roon Ready, Airplay, MQA, Qobuz, Deezer, Spotify Connect, Tidal, Tidal Connect, vTuner
SUPPORTED AUDIO FORMATS (NETWORK): Up to PCM 32bit/384kHz; DSD256 (DSF, DFF); AIFF (.aif, .aiff, .aifc); ALAC; WAV (.wav) packed/unpacked; FLAC; MP3; Apple Lossless; OGG; Monkey’s
IMPORTANT: UPnP server must support DSD streaming in order to stream DSD files.
SUPPORTED MEDIA SERVERS: All UPnP, DLNA, Roon
DIGITAL INPUTS: 1x RCA coaxial PCM asynchronous up to 24bit/192kHz, 1x AES/EBU balanced PCM asynchronous up to 24bit/192kHz, 2x TOS-Link PCM asynchronous up to 24bit/192kHz, 1x USB-B up to DSD512 and PCM up to 32bit/384kHz, 1x USB-A port DSD256 and PCM up to 32bit/384kHz, formatted in FAT32/NTFS (32Gb max for pen drives)
ANALOGUE INPUT: 1x 3.5mm mini-jack (input impedance 10kΩ)
AUDIO OUTPUTS: DAC: 1x unbalanced RCA @ 2Vrms, 1x balanced XLR @ 2Vrms
PREAMP: 1x unbalanced RCA, 1x balanced XLR, 1x headphone 6.3mm jack on front panel (double gain)
OUTPUT IMPEDANCE: 50Ω
POWER CONSUMPTION: 35W
FUSE: 2A F
POWER SUPPLY: 100-240V / 50-60Hz, Multiple Transformer proprietary power supply
DIMENSIONS: 200mm W | 80mm H | 260mm D
WEIGHT: 4 Kg– net, 5 Kg– boxed
REMOTE CONTROL: Multifunctional remote control included
